Si840x
Table 5. Electrical Characteristics for All I 2 C and Non-I 2 C Channels
3.0 V < VDD < 5.5 V. TA = –40 to +125 °C. Typical specs at 25 °C
Parameter
VDD Undervoltage Threshold
VDD Negative-going Lockout
Symbol
VDDUV+
VDDH–
Test Condition
AVDD, BVDD rising
AVDD, BVDD falling
Min
2.15
45
Typ
2.3
75
Max
2.5
95
Unit
V
mV
Hysteresis
Common Mode Transient
Immunity
Shut Down Time from UVLO
Start-up Time *
CMTI
t SD
t START
V I = V DD or 0 V
—
—
—
25
3.0
15
—
—
40
kV/μs
μs
μs
*Note: Start-up time is the time period from the application of power to valid data at the output.
1.4 V
Typical
Input
Typical
Output
1.4 V
t PLH
90%
10%
t r
90%
10%
t PHL
t f
Figure 1. Propagation Delay Timing (Non-I 2 C Channels)
1.1. Test Circuits
Figure 2 depicts the timing test diagram.
AVDD
BVDD
R 1
R 1
NC
NC
R 2
R 2
ASDA
ADIN
ADOUT
ASCL
BSDA
BDOUT
BDIN
BSCL
C 1
C 1
C 3
NC NC
AGND BGND
C 3
C 2
C 2
Si840x
Figure 2. Simplified Timing Test Diagram
8
Rev. 1.6
